🚀 Booster K1 Humanoid Robot — Product Overview

Product Summary

Product Name	Booster K1 Humanoid Robot
Manufacturer	Beijing Booster Robotics Co., Ltd.
Positioning	A developer-friendly humanoid platform designed for education, research, and robotics competitions such as RoboCup.
Height / Size	Approx. 95 cm
Degrees of Freedom	22 DoF
Weight	About 19.5 kg (including battery)
Computing Platform	NVIDIA Jetson Orin NX (40 TOPS version)
Control Mode	Full Force Control – supports torque, speed, and position hybrid control
Sensors / Inputs	RGB-D camera, 9-axis IMU, microphone array, speakers
Software Framework	Supports ROS 2 and provides low-level joint/sensor APIs and high-level motion APIs; compatible with Isaac Sim, MuJoCo, and Webots
Competition Support	Official RoboCup 3 v 3 demo project (open-sourced modules for vision, decision and game control)

🧠 Key Features & Technologies

1. Force-Control Actuators

K1’s dual-encoder actuators enable precise hybrid control of torque, velocity, and position, delivering smooth, natural, and impact-resistant motions.

2. AI Computing Platform — NVIDIA Orin NX (40 TOPS)

Based on NVIDIA Ampere architecture GPU with 512 CUDA cores and 64 Tensor Cores, the Orin NX provides up to 40 TOPS (INT8) AI inference performance. It supports TensorRT, CUDA, cuDNN, and DeepStream for optimized deep learning deployment. With 10–25 W power consumption, it achieves a strong balance between performance and battery life, enabling on-device vision processing, speech recognition, and motion planning without cloud dependency.

3. Open Software Ecosystem

Full ROS 2 integration with compatibility for Gazebo, Isaac Sim, MuJoCo, and Webots. An official open-source RoboCup framework is available on GitHub, including modules for vision, decision-making, and game control. Developers can freely customize AI modules and control algorithms.

4. Education & Research Friendly

Provides SDK and Python / C++ APIs for robotics and AI teaching. Ideal for experiments in reinforcement learning, humanoid locomotion, and multi-sensor fusion.

5. Extensible Design

Supports 5G / Wi-Fi communication for remote control and multi-robot coordination. Modular hardware design allows easy replacement or addition of cameras, joints, and sensors.

⚙️ NVIDIA Jetson Orin NX (40 TOPS) Specifications

AI Performance	Up to 40 TOPS (INT8) AI inference performance
GPU	Ampere architecture, 512 CUDA cores + 64 Tensor Cores
CPU	6-core Arm Cortex-A78AE @ 1.9 GHz
Memory	8 GB LPDDR5 (102 GB/s bandwidth)
Power Modes	Configurable from 10 W to 25 W
Camera Interfaces	3 × CSI channels, supports 4K @ 60 fps input
I/O Expansion	USB 3.2, Ethernet, UART, I²C, SPI, and more
AI Framework Support	TensorRT, CUDA, PyTorch, TensorFlow, DeepStream, cuDNN, etc.

Compared with the 117 TOPS (16 GB) version, the 40 TOPS variant offers lower power consumption and excellent energy efficiency, making it ideal for medium-sized humanoid robots, academic projects, and embedded AI applications.

📥 Download Full Booster K1 Brochure (PDF)
